| Proizvajalčeva koda | 90MB1D80-M1EAY0 |
| EAN koda | 4711387014509 |
| Proizvajalec | ASUS |
| Podnožje: | LGA1700 |
| Vezni nabor: | Intel Z790 |
| format_filter_matične | ATX |
| Pomnilnik: | 4x DIMM slot, Max. 192GB, DDR5 7200(OC) |
| Razširitvena mesta: | Intel Core Processors (14th & 13th & 12th Gen)*
1x PCIe 5.0 x16 slot
Intel® Z790 Chipset
1x PCIe 4.0 x16 slot (supports x4 mode)
1x PCIe 4.0 x4 slot
2x PCIe 3.0 x1 slots
|
| SATA/IDE | 4x SATA 6Gb/s ports |
| Shranjevanje: | Skupno podpira 4x M.2 slots and 4x SATA 6Gb/s port*
Intel® Core™ Processors (14th & 13th & 12th Gen)
M.2_1 slot (Key M), type 2242/2260/2280/22110
- Intel® 13th & 12th Gen processors support PCIe 4.0 x4 mode
Intel® Z790 Chipset
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)
4x SATA 6Gb/s ports
* Intel® Rapid Storage Technology podpira PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10. |
| zvočna_kartica | Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC |
| stevilo_usb_prikljuckov | Zadaj USB (skupno 8)
1x USB 3.2 Gen 2x2 port (1 x USB Type-C®)
3x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C®)
4x USB 3.2 Gen 1 ports (4 x Type-A)
Spredaj USB (skupno 7)
1x USB 3.2 Gen 2 connector (supports USB Type-C®)
1x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
2x USB 2.0 headers support additional 4 USB 2.0 ports |
| Mrežna kartica | 1x Intel 2.5Gb Ethernet (TUF LANGuard) |
| Zunanji konektorji: | 1x USB 3.2 Gen 2x2 port (1 x USB Type-C®)
3x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C®)
4x USB 3.2 Gen 1 ports (4 x Type-A)
1x DisplayPort
1x HDMI® port
1x Wi-Fi Module
1x Intel® 2.5Gb Ethernet port
5x Audio jacks
1x Optical S/PDIF out port
|
| Notranji konektorji: | Ventilator in hlajenje
1x 4-pin CPU Fan header
1x 4-pin CPU OPT Fan header
1x 4-pin AIO Pump header
4x 4-pin Chassis Fan headers
Napajanje
1x 24-pin Main Power connector
2x 8-pin +12V Power connectors
Shranjevanje
4x M.2 slots (Key M)
4x SATA 6Gb/s ports
USB
1x USB 3.2 Gen 2 connector (supports USB Type-C®)
1x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
2x USB 2.0 headers support additional 4 USB 2.0 ports
Drugo
3x Addressable Gen 2 headers
1x Aura RGB header
1x Clear CMOS header
1x COM Port header
1x Front Panel Audio header (AAFP)
1x 20-3 pin System Panel header with Chassis intrude function
1x Thunderbolt™ (USB4®) header |
| Dodatno: | Brezična povezava in Bluetooth
Wi-Fi 6E
2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
Podpira frekvenčni pas 2,4/5/6GHz*
Bluetooth v5.3*
* Predpisi za WiFi 6E 6GHz se lahko med državami razlikujejo.
|
| Vsebina paketa: | Kabli
2x SATA 6Gb/s cables
Drugo
1x ASUS Wi-Fi moving antenna
1x TUF GAMING sticker
2x M.2 Rubber Packages
1x Screw package for M.2 SSD
Dokumentacija
1x TUF Certification card
1x navodila |
| Garancija | 36 mesecev |
